Scheduled Tasks¶
On the left side of web Admin Panel -> SYSTEM -> Scheduled Tasks
Schedule Tasks allows you to set up a daily schedule for some basic actions, such as turning LED lights on and off, restarting the router, turning Wi-Fi on and off, and switching TX power.
Note: Please first synchronize the time in the Time Zone before using this function. If the device is shut down at the scheduled time, the task will not be executed.
LED Display Schedule¶
This feature allows you to set a schedule for your router's LED lights.
When enabled, set the on and off times, select the weekly effective dates, and then click Apply.
Schedule Reboot¶
This feature allows you to set a schedule for automatically restarting your router.
When enabled, set the reboot times, select the weekly effective dates, and then click Apply.
Wi-Fi Schedule¶
This feature allows you to set Wi-Fi schedules based on the Wi-Fi frequency bands supported by your router (such as 2.4 GHz, 5 GHz, 6 GHz, and MLO Wi-Fi).
Except for MLO Wi-Fi, which only supports the on/off schedule mode, all other Wi-Fi frequency bands support two schedule modes: Turn On/Off and Switch TX Power.
-
Turn On/Off: It helps balance connectivity convenience and energy conservation by automatically enabling or disabling the wireless network at specific times (e.g., turning it off during sleep hours to reduce unnecessary power consumption).
-
Switch TX Power: It refers to adjusting wireless transmission power (which determines signal strength and coverage) automatically at specific times, balancing performance and energy efficiency (e.g., reducing power during low usage).
MLO Wi-Fi Schedule¶
| Supported Models | |
|---|---|
| GL-BE6500 (Flint 3e) | √ |
| GL-BE9300 (Flint 3) | √ |
| GL-BE3600 (Slate 7) | √ |
| GL-MT3600BE (Beryl 7) | √ |
You can set an on/off schedule for both the MLO Main Wi-Fi and Guest Wi-Fi.
Enable the Main or Guest Wi-Fi Schedule, set the on and off times, select the weekly effective dates, and then click Apply.
6 GHz Wi-Fi Schedule¶
| Supported Models | |
|---|---|
| GL-BE9300 (Flint 3) | √ |
When the Wi-Fi schedule mode is Turn On/Off, you can set an on/off schedule for both the 6 GHz Main Wi-Fi and Guest Wi-Fi.
Enable the Main or Guest Wi-Fi Schedule, set the on and off times, select the weekly effective dates, and then click Apply.
When the Wi-Fi schedule mode is Switch TX Power, you can set a TX power switching schedule for the 6 GHz Main Wi-Fi. Note that 6 GHz Guest Wi-Fi is not supported for this schedule mode.
Enable the Main Wi-Fi Schedule, set two timed actions to switch TX power, select the weekly effective dates, and then click Apply.
- Switch: Set TX Power to a certain level (e.g., Low) at a specific time (e.g., 22:00).
- Restore: Restore TX Power to another level (e.g., Max) at another time (e.g., 07:00).
- days: Select the effective days of the week for these settings.
5 GHz Wi-Fi Schedule¶
When the Wi-Fi schedule mode is Turn On/Off, you can set an on/off schedule for both the 5 GHz Main Wi-Fi and Guest Wi-Fi.
Enable the Main or Guest Wi-Fi Schedule, set the on and off times, select the weekly effective dates, and then click Apply.
When the Wi-Fi schedule mode is Switch TX Power, you can set a TX power switching schedule for the 5 GHz Main Wi-Fi. Note that 5 GHz Guest Wi-Fi is not supported for this schedule mode.
Enable the Main Wi-Fi Schedule, set two timed actions to switch TX power, select the weekly effective dates, and then click Apply.
- Switch: Set TX Power to a certain level (e.g., Low) at a specific time (e.g., 22:00).
- Restore: Restore TX Power to another level (e.g., Max) at another time (e.g., 07:00).
- days: Select the effective days of the week for these settings.
2.4 GHz Wi-Fi Schedule¶
When the Wi-Fi schedule mode is Turn On/Off, you can set an on/off schedule for both the 2.4 GHz Main Wi-Fi and Guest Wi-Fi.
Enable the Main or Guest Wi-Fi Schedule, set the on and off times, select the weekly effective dates, and then click Apply.
When the Wi-Fi schedule mode is Switch TX Power, you can set a TX power switching schedule for the 2.4 GHz Main Wi-Fi. Note that 2.4 GHz Guest Wi-Fi is not supported for this schedule mode.
Enable the Main Wi-Fi Schedule, set two timed actions to switch TX power, select the weekly effective dates, and then click Apply.
- Switch: Set TX Power to a certain level (e.g., Low) at a specific time (e.g., 22:00).
- Restore: Restore TX Power to another level (e.g., Max) at another time (e.g., 07:00).
- days: Select the effective days of the week for these settings.
